TangoFactory
- class TangoFactory(*p, **k)[source]
A
TaurusFactorysingleton class to provide Tango-specific Taurus Element objects (TangoAuthority, TangoDevice, TangoAttribute)Tango model names are URI based See https://tools.ietf.org/html/rfc3986. For example, a TangoAttribute would be:
tango://foo.org:1234/a/b/c/d#label \___/ \_____/ \__/ \_____/ \___/ | | | | | | hostname port attr | | \____________/\______/ | | | | | scheme authority path fragment
For Tango Elements:
The ‘scheme’ must be the string “tango” (lowercase mandatory)
The ‘authority’ identifies the Tango database (<hostname> and <port> are mandatory if authority is given)
The ‘path’ identifies Tango Device and Attributes. For devices it must have the format _/_/_ or alias For attributes it must have the format _/_/_/_ or devalias/_
The ‘fragment’ is optional and it refers to a member of the model object, thus not being part of the model name itself
Import from
taurus.core.tangoas:from taurus.core.tango import TangoFactory
- caseSensitive = False
- elementTypesMap = {3: <class 'taurus.core.tango.tangodevice.TangoDevice'>, 13: <class 'taurus.core.tango.tangoattribute.TangoAttribute'>, 18: <class 'taurus.core.tango.tangodatabase.TangoAuthority'>}
- getAttribute(attr_name, create_if_needed=True, **kwargs)[source]
Obtain the object corresponding to the given attribute name. If the corresponding attribute already exists, the existing instance is returned. Otherwise a new instance is stored and returned.
- Parameters:
- Returns:
attribute object :raise: (taurus.core.taurusexception.TaurusException) if the given alias is invalid.
- Return type:
taurus.core.tangoattribute.TangoAttribute
- getAttributeInfo(full_attr_name)[source]
Deprecated: Use
taurus.core.tango.TangoFactory.getConfiguration()instead.Obtain attribute information corresponding to the given attribute name. If the corresponding attribute info already exists, the existing information is returned. Otherwise a new information instance is stored and returned.
- Parameters:
full_attr_name (str) – attribute name in format: <tango device name>’/’<attribute name>
- Returns:
configuration object
- Return type:
- getAuthority(name=None)[source]
Obtain the object corresponding to the given database name or the default database if name is None. If the corresponding authority object already exists, the existing instance is returned (including reuse of a cached default authority). Otherwise a new instance is stored and returned.
- Parameters:
name (str) – database name string alias. If None, the default database is used.
- Returns:
database object
- Raise:
taurus.core.taurusexception.TaurusException if the given alias is invalid.
- Return type:
taurus.core.tangodatabase.TangoAuthority
- getConfiguration(**kwargs)
- Obtain the object corresponding to the given attribute or full name.
If the corresponding configuration already exists, the existing instance is returned. Otherwise a new instance is stored and returned.
- param param:
attribute object or full configuration name
- type param:
taurus.core.taurusattribute.TaurusAttribute or str
- return:
configuration object
- rtype:
taurus.core.tango.TangoAttribute
Deprecated since version 4.0: Use getAttribute instead
- getDevice(dev_name, create_if_needed=True, **kw)[source]
Obtain the object corresponding to the given tango device name. If the corresponding device already exists, the existing instance is returned. Otherwise a new instance is stored and returned.
- Parameters:
dev_name (str) – tango device name or tango alias for the device. It must be a valid Tango device URI. If authority is not explicit, the default Tango Database will be used
create_if_needed (bool) – If True, the Device is created if it did not exist previously. If False, it returns None if it did not exist
- Returns:
a device object :raise: (taurus.core.taurusexception.TaurusException) if the given dev_name is invalid.
- Return type:
- getExistingAttributes()[source]
Returns a new dictionary will all registered attributes on this factory
- Returns:
dictionary will all registered attributes on this factory
- Return type:
- getExistingDatabases()[source]
Returns a new dictionary will all registered databases on this factory
- Returns:
dictionary will all registered databases on this factory
- Return type:
- getExistingDevices()[source]
Returns a new dictionary will all registered devices on this factory
- Returns:
dictionary will all registered devices on this factory
- Return type:
- isPollingEnabled()[source]
Tells if the local tango polling is enabled
- Returns:
wheter or not the polling is enabled
- Return type:
- is_tango_subscribe_enabled(**kwargs)
Returns the current tango_subscribe_enabled status
Warning
This method belongs to a “Delayed Event Subscription” API added in v.4.2.1-alpha as an experimental feature. This API may not be stable and/or it may be removed in a future release (even on a minor version change)
Deprecated since version 5.2.1: Use is_tango_event_subscription_disabled instead
- registerAttributeClass(attr_name, attr_klass)[source]
Registers a new attribute class for the attribute name.
- Parameters:
attr_name (str) – attribute name
attr_klass (taurus.core.tango.TangoAttribute) – the new class that will handle the attribute
- registerDeviceClass(dev_klass_name, dev_klass)[source]
Registers a new python class to handle tango devices of the given tango class name
- Parameters:
dev_klass_name (str) – tango device class name
dev_klass (taurus.core.tango.TangoDevice) – the new class that will handle devices of the given tango class name
- removeExistingAttribute(attr_or_attr_name)[source]
Removes a previously registered attribute.
- Parameters:
attr_or_attr_name (str or TangoAttribute) – attribute name or attribute object
- removeExistingDevice(dev_or_dev_name)[source]
Removes a previously registered device.
- Parameters:
dev_or_dev_name (str or TangoDevice) – device name or device object
- schemes = ('tango', 'tango-nodb')
- setOperationMode(mode)[source]
Deprecated. setOperationMode(OperationMode mode) -> None Sets the operation mode for the Tango system.
- set_default_tango_host(tango_host)[source]
Sets the new default tango host. The method will transform the given name to an Authority URI.
Note
Calling this method also clears the device alias cache.
- Parameters:
tango_host (str) – the new tango host. It accepts any valid Tango authority name or None to use the defined by $TANGO_HOST env. var.
- set_tango_event_subscription_disabled(disable_subscription)[source]
Disable subscription to tango events. Needs to be called before creating Attributes or setting models
- set_tango_subscribe_enabled(**kwargs)
If True, enables event subscribing on TangoAttribute objects
Warning
This method belongs to a “Delayed Event Subscription” API added in v.4.2.1-alpha as an experimental feature. This API may not be stable and/or it may be removed in a future release (even on a minor version change)
Deprecated since version 5.2.1: Use set_tango_event_subscription_disabled instead
